Description

The A-30 Direct Energy Design amplifiers with Symmetrical Construction offer class-leading, high quality sound, wrapped in understated, technical elegance.

The brushed aluminium front panel comes with polished-black, aluminium control knobs for Volume, Bass / Treble / Balance and Input Source adjustments, whilst a selection of blue LED buttons fine-tune Loudness, Speaker A/B, Power Amp Direct and confirm your choice of Input Source.

The rear panel is designed to meet the audio requirements of multiple systems and provide immediate connectivity to Aux-In, Network, Recorder, Power Amp Direct, Speaker A + B and 'Source Direct Mode' devices.

Exclusive to this mid-range model:

Symmetrical Construction
Clean Ground Construction
Power Amp Direct Mode
5 tacticle keys including Power Amp Direct
A trans-stabiliser
12 blue LED indicators
Motorised aluminium Volume Knob.
Remote included

The A-30 is available in finishes Black and Silver.

AUDIO FEATURES

Direct Energy Design Amp
Symmetrical Power Amp
Clean Ground Construction
Isolated Power Supply
Source Direct Mode
Power Amp Direct Mode
Trans-Stabilizer
Speaker A, B, A+B Selector
Aluminium Rotary Knob
Aluminium Panels
Auto Power Down

CONNECTIONS

Analogue Audio Input (PHONO (MM), TUNER, SACD/CD, AUX, NETWORK, RECORDER, POWER AMP DIRECT IN)
Audio Output (RECORDER, PHONES)
SR In/Out
AC Inlet

OTHER FEATURES

70 W + 70 W (20 Hz-20 kHz, THD 0.1 %, 4 ohms)
40 W + 40 W (20 Hz-20 kHz, THD 0.05 %, 8 ohms)
THD: 0.01 % (Rated Output -3 dB, 8 ohms, 1 kHz)
Guaranteed Speaker Impedance (2 Speaker Terminals):
- 4-16 ohms (A or B), 8-32 ohms (A+B), 4-16 ohms (Bi-Wiring)
Frequency Response: SACD/CD 5 Hz-100 kHz, 0 dB/-3 dB, PHONO (RIAA Equalization) MM 20 Hz-20 kHz, ±0.5 dB
Signal-to-Noise Ratio (IHF, A Network, Short Circuited)
- SACD/CD: 105 dB, Phono: 77 dB (MM: 5 mV input),Power Amp Direct: 118 dB
Channel Separation
- SACD/CD: 90 dB (100 Hz), 90 dB (1 kHz), 75 dB (10 kHz)
- Power Amp Direct: 90 dB (100 Hz), 90 dB (1 kHz), 85 dB (10 kHz)
Power Requirements: AC 220-230 V, 50 Hz
Power Consumption: 175 W
Power Consumption During Standby: 0.3 W

DIMENSIONS & WEIGHT
