Topping D70 Pro OCTO Desktop DAC 8x CS43198 XMOS XU316 Bluetooth 5.1

Topping D70 Pro OCTO Desktop DAC 8x CS43198 XMOS XU316 Bluetooth 5.1

• 8-core driver with Cirrus Logic flagship chips
• Supports up to PCM768kHz/32bit and DSD512 audio decoding
• Full-color screen with customizable displays
• Bluetooth 5.1 with multiple audio encoding support
• Versatile output modes, including RCA and XLR
• Integrated preamp function with independent volume memory
• 12V Trigger for synchronous device switching

The D70 Pro OCTO is equipped with 8 Cirrus Logic flagship chips (CS43198), offering a robust 8-core driver setup. With support for up to PCM768kHz/32bit and DSD512 audio decoding, the D70 Pro OCTO brings you an even more superior music experience, reaching a whole new level, with all the details perfectly displayed. The full-color screen and three touch buttons of the D70 Pro OCTO introduce a refreshing UI experience. The display of the playback information, FFT, or VU, tcan be switched according to your requirements.

Bluetooth 5.1

The D70 Pro OCTO supports LDAC/aptX-Adaptive/apt HD/apt/AAC/SBC audio encoding, allowing high-quality audio wirelessly for a better sound experience.

Plug and play

The D70 Pro OCTO has wide compatibility and can be used on multiple operating systems such as Windows 10, Windows 11, MAC, Linux, iOS/Android, and more. And for Windows users who need ASIO applications, the stable and reliable XMOS XU316 and Thesycon custom driver make setup a breeze.

Output modes

Whether you need RCA single-ended output, XL balanced output, or both, the D70 Pro OCTO has yprovides you with a more convenient and efficient way to output. Freely switch between output modes to adapt to different devices and performance needs.

Integrated preamp & independent volume memory

In addition to the fixed output level DAC mode, the D70 Pro OCTO also has a preamp mode. Adjust volume and output directly to power amplifiers or active speakers. With independent volume memory for different modes, you’ll always return to your last-used volume setting.

Specifications:

RCA

THD+N @A-wt: <0.00008% @1KHz

THD @No-wt 90kBw: <0.0004% @20-20kHz

SNR @A-wt: 128dB @1kHz

Dynamic Range @A-wt: 128dB @1kHz

Frequency Response: 20Hz-20kHz(+0.05dB) // 20Hz-40kHz(+0.2dB)

Output Level: 2.1 Vrms @0dBFS(4V Mode) // 2.6Vrms @OdBFS(5V Mode)

Noise @A-wt: <1.0uVrms

Channel Crosstalk: -124dB @1kHz

Channel Balance: 0.3dB

Output Impedance: 50Ω

XLR

THD+N @A-wt: <0.00007% @1kHz

THD @No-wt 90kBw: <0.0002% @20-20kHz

SNR @A-wt: 134dB @ 1kHz

Dynamic Range @A-wt: 134dB @1kHz

Frequency Response: 20Hz-20kHz(+0.05dB) // 20Hz-40kHz(+0.2dB)

Output Level: 4.2Vrms @0dBFS(4V Mode) // 5.2Vrms @OdBFS(5V Mode)

Noise @A-wt: <1.0uVrms

Channel Crosstalk: -149dB @1kHz

Channel Balance: 0.3dB

Output Impedance: 100Ω

List of items included:

- D7 Pro OCTO

- Remote control

- USB cable

- AC cable

- Bluetooth antenna

- Quick start guide
