Sommer Cable Microphone Cable - non terminated, price per meter.

Double... shields better. Just like the SC-SYMBIOTIC, but a little bit more exclusive due to the double counter-rotating copper spiral shielding and the wire pairs embedded in PVC. This makes it even more flexible. Because of the thicker wire diameter (2 x 0.38 mm²) it is suitable for distances of more than 100 meters. This cable is technically sound and may be the best microphone cable on the world market. Your clients in the recording studio will be surprised by the noise-free transmission!

On the SC-GALILEO 238 Plus (Article-No. 200-0271) the two counter-rotating spiral shields were insulated separately with a non-conductive foil. This separation of the grounding shields is very often used in professional sound studios and in broadcasting.

THE ADVANTAGES:

- Extreme long life and twist-proof due to the thick jacket and the wire pairs embedded in PVC.
- Absolutely neutral and loss-free audio transmission due to the use of fine copper strands.
- Excellent protection due to the dense counter-rotating double spiral shielding
- Very flexible due to the dense wire stranding
- Loss-free transmission over long distances due to a large wire diameter of 2 x 0.38 mm²

THE APPLICATION:

- Highly professional studio and stage technology
- Demanding OB Van technology for radio and broadcasting
- First class HiFi-connection (conductor red and white on Pin1, shielding separately)

TECHNICAL DATA:
Construction (2LI2Y0.38mm2)YDDY
Jacket, diameter PVC 7,0 mm
AWG 21
No. of inner conductors 2 x 0,38 mm2
Copper strand per conductor 48 x 0,10 mm
Conductor insulation PE 1,55 mm
Shielding double copper spiral, counter-rotating + polyester tape
Shielding factor 100 %
Temperature range min. -30 °C
Temperature range max. 70 °C
Fire load per m 0,22 kWh
Weight per 1 m 60 g
Colour black

ELECTRICAL DATA:
Capac. cond./cond. per 1 m 50 pF
Capac. cond./shield. per 1 m 100 pF
Cond. resistance per 1 km < 52 Ohm
Shield. resistance per 1 km 20 Ohm
Insulation resist. per 1 km > 1 GOhm
Surge impedance 38 Ohm
